IGG318263 clamp mount for 2 monitors 17" to 32" black
33,26 €
VAT included · Delivery to mainland Spain and the Balearic Islands
Shipping: 6,05 €
Typical transit after dispatch: 24 h to mainland Spain and 48 h to the Balearic Islands. Estimate depends on destination and availability.
In stock
Total including shipping: 39,31 € · Free shipping from 301,00 €
iggual clamp mount for two 17" to 32" monitors with VESA 75x75 and 100x100. Each arm supports up to 8 kg and allows tilt, swivel and rotation. Includes cable management guide.
About this product
The iggual IGG318263 clamp mount is designed to hold two 17" to 32" monitors on a desk. It is compatible with VESA 75x75 and 100x100 mm patterns, and each arm supports a maximum weight of 8 kg. The arms are adjustable via a spring and chain-assisted mechanism, making it easier to position the screens. It allows a tilt of +55°/-55°, a swivel of +90°/-90° and a rotation of +180°/-180°. The adjustable height ranges from 155 mm to 445 mm, and the maximum arm extension is 515 mm. Installation is done via a clamp or through-hole bolt: the clamp opening accepts 1 to 8 cm and the through-hole bolt depth 1 to 4.5 cm. It features a cable management guide to keep wiring tidy and is compatible with curved screens. The finish is black. The product includes a manual, screws and installation instructions, and complies with RoHS specifications.
What can you use it for?
- Mount two 17" to 32" monitors on a desk to work with multiple windows or applications at once.
- Adjust the tilt, swivel and rotation of each screen to find a comfortable viewing angle.
- Keep monitor cables organised thanks to the integrated cable management guide.
Its strengths
- Compatible with 17" to 32" monitors and VESA 75x75 and 100x100 mm patterns.
- Each arm supports up to 8 kg of weight.
- Allows tilting, swivelling and rotating the screens to adapt the position.
Things to consider before buying
- Before buying, check that your desk or surface allows clamp mounting (opening 1 to 8 cm) or through-hole bolt mounting (depth 1 to 4.5 cm).
- The net weight of the mount is 3.9 kg; make sure the mounting point can support it together with the monitors.
Product questions
What monitor sizes does this mount support?
It supports monitors from 17" to 32" and is compatible with VESA 75x75 and 100x100 mm patterns.
How much weight does each arm support?
Each arm supports a maximum weight of 8 kg.
How is it installed on the desk?
It can be installed via a clamp or a through-hole bolt. The clamp opening accepts 1 to 8 cm and the through-hole bolt depth 1 to 4.5 cm.
ALMC analysis prepared with AI assistance using the supplier’s product information. It is not a product test or a customer review. Check the specifications and confirm the compatibility you need.
Technical specifications
¿No sabes cómo colocar el monitor sobre tu escritorio para disfrutar del mejor ángulo de visión?
Los soportes articulables de iggual, para una y dos pantallas de hasta 32”, se convertirán en tu mayor aliado. Podrás inclinarlo hasta 55°, girarlo 90° o rotarlo 180°. Y todavía hay más. Estos accesorios premium, totalmente flexibles y resistentes, te ayudarán a ganar espacio en tu escritorio y a mantenerlo ordenado gracias a la guía para cables que incluyen. Además, son capaces de soportar hasta 8 kg de peso y son muy fáciles de instalar.
| Marca | iggual |
| Modelo | IGG318263 |
| Características | - Monitores soportados: 17" - 32" - VESA: 75x75 y 100x100 - Peso máximo soportado: 8 kg por brazo - Brazos regulables con mecanismo asistido por muelles y cadenas - Ángulos: Inclinación: +55°/-55° Giro: +90°/-90° Rotación: +180°/-180° - Alturas: 155 mm (mín) / 445 mm (máx) - Extensión máxima de los brazos: 515 mm - Instalación mediante abrazadera o tornillo pasante - Apertura abrazadera: 1 a 8 cm - Profundidad tornillo pasante: 1 a 4,5 cm - Sistema de guía pasacables - Compatible con pantallas curvas - Color: negro - Peso neto: 3,9 kg - Peso bruto: 4,5 kg - Medidas (embalaje): 415 x 245 x 115 mm - Incluye manual, tornillería e instrucciones de instalación - Cumple especificaciones RoHS |
| Fecha de revisión | 05-09-2024 por RTY |
Product identifiers
| Reference | AISATV0316 |
|---|---|
| EAN | 8435364318263 |
| Part number | IGG318263 |
| Manufacturer | iggual |
